Key Features
- Pre-configured for use with Simrad, Lowrance and B&G MFDs
- Fast setup on each MFDs
- Rugged 316 Marine Grade Stainless Steel Housing
- 1.8mm 160 deg viewing angle - See the entire deck
- Compatible with NOS 20.2 or later
- Built In IR LED Illumination (10m Range)
- PoE IEEE802.3af Power Option
- Extremely Low Power Consumption
- IP66 Environmental Protection
Specifications
| DC | 12V DC (10-16V) DC 2.1/5.5mm Male CCTV power connector |
| IR LED Off | 1.38W (0.1A at 13.8V DC) |
| IR LED On | 2.76W (0.2A at 13.8V DC) |
| Operating temperature | -30 degC to +60 degC (-22 degF to 140 degF) |
| IP Rating | IP66 |
| Main stream | 1080p (1920x1080) |
| Sub Stream | 448p (800x448) |
| Protocol | RTSP |
| Lens | 1.8mm (160 deg Wide Angle) |
| Sensor | 1/4 CMOS |
| Housing | 316 Stainless steel |
| Weight | 420g |
